Sauce, Ketchup and Mayonnaise Processing Line

Sauce, Ketchup and Mayonnaise Processing Line

A recipe-driven hygienic line for mixing, emulsifying, deaerating, heating, cooling and filling sauces, ketchup, mayonnaise and dressings.

AgriTech.tr prepares this entry as a supplier-neutral technical sourcing scope so buyers can define a comparable request before suitable suppliers are researched and confirmed during sourcing. It does not reproduce a single vendor catalogue. Depending on the project, the potential scope may include local equipment and services or imported specialist components where technically necessary; the actual supplier and origin are confirmed during the quotation process.

Technical sourcing scope

The values below are not guaranteed single-model performance. They are typical, configurable procurement envelopes used to place competing quotations on the same engineering basis. Capacity, recipe, climate, water analysis, feedstock properties, target quality, utilities, and destination-country requirements are frozen in the final project schedule.

Process and integration sequence

1. Dose water, oil, tomato base, powders and minor ingredients by recipe.
2. Mix, homogenize or emulsify under controlled shear and vacuum.
3. Apply the scheduled thermal process and verify critical parameters.
4. Fill, close, code and release product under the plant HACCP plan.

The line or system boundary is documented through a responsibility matrix covering reception and infeed, process equipment, automation, safety, product discharge, utility interfaces, and data records. For brownfield integration, electrical single lines, piping and instrumentation, floor/loading data, drainage, ventilation, water quality, compressed air, steam, refrigeration, and network interfaces are reviewed before order.

Suitable applications

• Tomato ketchup and cooking sauces
• Mayonnaise and emulsified dressings
• Pepper and vegetable sauces
• Food-service and retail condiments

Engineering, compliance, and acceptance

• Quotations are compared against the same feed or product specification, inlet condition, shift pattern, net capacity, and target output quality.
• Food-contact materials, machine safety, electrical panels, pressure equipment, refrigerants, emissions, occupational safety, and hygienic design are specified for the destination and the actual process risk.
• Factory and site acceptance tests define the measurement method, sample size, tolerances, run duration, rejection criteria, and correction period in writing.
• The procurement dossier requests a revision-controlled technical schedule, equipment and motor lists, material specifications, utility consumption, critical spares, preventive maintenance, manuals, and operator training.
• Capacity, yield, energy, water, product-loss, quality, or biological-performance statements are not treated as guarantees without the actual design inputs and an agreed acceptance test.

How to compare quotations

• Minimum and maximum batch size
• Emulsion stability and agreed test method
• Dosing accuracy and recipe traceability
• Scheduled-process and equilibrium-pH validation
• Allergen changeover and CIP duration

Buyers should request at least three comparable quotations, references for similar installations in Türkiye, CE/conformity documentation, warranty boundaries, critical-spares lead times, and after-sales response commitments. This makes lifecycle cost, operability, and local service capacity visible alongside the purchase price.

Technical references

• FDA acidified and low-acid food guidance
• EU JRC Food, Drink and Milk Industries BREF
• Codex food-hygiene codes of practice

The references support process principles and design boundaries; they do not certify a particular supplier’s performance. Final acceptance is based on the selected supplier’s written offer, project engineering, site review, and FAT/SAT protocol.
